Assay to Evaluate BAL Fluid Regulation of Fibroblast α-SMA Expression

Materials and Reagents

1. 6-well cell culture plates (Corning, Costar^®, catalog number: 3516 )

2. Normal human fibroblasts (IMR-90) (ATCC, catalog number: CCL-186 )

3. DMEM

4. Fetal bovine serum (FBS) (Thermo Fisher Scientific, Gibco^TM, catalog number: 26140095 )

5. Penicillin-streptomycin (10,000 U/ml, 10,000 µg/ml) (Thermo Fisher Scientific, Gibco^TM, catalog number: 15140122 )

6. Amphotericin B (Thermo Fisher Scientific, Gibco^TM, catalog number: 15290018 )

7. RPMI 1640 medium, no phenol red (Thermo Fisher Scientific, Gibco^TM, catalog number: 11835030 )

8. DPBS (Thermo Fisher Scientific, Gibco^TM, catalog number: 14190144 )

9. NP-40

10. Sodium chloride (NaCl)

11. Protease inhibitor tablets (Sigma-Aldrich, catalog number: 11836170001 )

12. Phosphatase inhibitor (EMD Millipore, catalog number: 524625 )

13. α-SMA antibody (American Research Products, catalog number: 03-61001 )

14. β-actin antibody (Sigma-Aldrich, catalog number: A5441 )

15. Tween 20

16. Fibroblast culture media (see Recipes)

17. Lysis buffer (see Recipes)


Equipment

1. Cell culture incubator, 37 °C, 5% CO₂: 95% air atmosphere (Thermo Fisher Scientific, Forma^TM, model: Direct Heat CO₂ Incubator )

Procedure

1. Seed fibroblasts at a density of 1 x 10⁶ per well of a 6-well cell culture plate in a total volume of 1 ml. Allow cells to adhere to cell culture plate (2-6 h).

2. Harvest bronchoalveolar lavage (BAL) fluid from mice (Han and Ziegler, 2013). Mice can be treated with bleomycin (1.75 U/kg) or saline as a negative control. Determine the protein concentration of bronchoalveolar lavage (BAL) fluid. Using RPMI 1640 media, normalize all BAL samples to the same protein concentration in a total volume of 1 ml.
   Notes:
1. Typically, 0.5-1 ml of BAL fluid is used and RPMI is used to normalize the protein concentration to a final total volume of 1 ml.

2. Alternatively, this assay can be performed in vitro using conditioned media from macrophage cell lines or bone marrow derived macrophages. Harvest the conditioned media from macrophages post-transfection or post-treatment, using 1 million cells per 1 ml of media.

3. Remove media from fibroblasts and rinse with 1.5 ml room temperature 1x PBS, add normalized BAL fluid to fibroblasts.

1. Incubate fibroblasts with BAL fluid for 24 h in a cell culture incubator, 37 °C, 5% CO₂: 95% air atmosphere.

2. Harvest fibroblasts by lysing cells in lysis buffer (see Recipes).

4. Determine α-SMA expression by immunoblot analysis. The expression of α-SMA protein was determined by Western blotting using 20 μg of total cellular protein. After blocking in 5% milk, the membranes were probed with mouse α-SMA primary antibody using a 1:3,000 dilution in Tris buffered saline containing 0.1% Tween 20, the membranes were incubated with the anti-mouse secondary antibody (1:2,000) in antibody dilution buffer for 1 h.


Data analysis

Results can be shown as a representative immunoblot (Figure 1); also see Larson-Casey et al. (2016).


Figure 1. Immunoblot analysis of α-SMA in IMR-90 fibroblasts cultured in BAL fluid (BALF) from saline or bleomycin (Bleo) exposed WT mice

Recipes

1. Fibroblast culture media
   DMEM
   10% heat-inactivated FBS
   100 U/ml, 100 μg/ml penicillin-streptomycin
   1.25 μg/ml amphotericin B (fungizone)

2. Lysis buffer
   1% NP-40
   0.15 M NaCl
   0.05 M Tris pH 7.4
   1 protease tablet
   Phosphatase inhibitor diluted 1:100


Acknowledgments

This work was supported by 2R01ES015981 & VA merit review BX001135.

References

1. Desmoulière, A., Geinoz, A., Gabbiani, F. and Gabbiani, G. (1993). Transforming growth factor-beta 1 induces alpha-smooth muscle actin expression in granulation tissue myofibroblasts and in quiescent and growing cultured fibroblasts. J Cell Biol 122(1): 103-111.

2. Han, H. and Ziegler, S. F. (2013). Bronchoalveolar lavage and lung tissue digestion. Bio-protocol 3(16): e859.

3. He, C., Murthy, S., McCormick, M. L., Spitz, D. R., Ryan, A. J. and Carter, A. B. (2011). Mitochondrial Cu,Zn-superoxide dismutase mediates pulmonary fibrosis by augmenting H₂O₂ generation. J Biol Chem 286(17): 15597-15607.

4. Horowitz, J. C., Rogers, D. S., Sharma, V., Vittal, R., White, E. S., Cui, Z. and Thannickal, V. J. (2007). Combinatorial activation of FAK and AKT by transforming growth factor-beta1 confers an anoikis-resistant phenotype to myofibroblasts. Cell Signal 19(4): 761-771.

5. Larson-Casey, J. L., Deshane, J. S., Ryan, A. J., Thannickal, V. J. and Carter, A. B. (2016). Macrophage Akt1 kinase-mediated mitophagy modulates apoptosis resistance and pulmonary fibrosis. Immunity 44(3): 582-596.

6. Sime, P. J., Xing, Z., Graham, F. L., Csaky, K. G. and Gauldie, J. (1997). Adenovector-mediated gene transfer of active transforming growth factor-beta1 induces prolonged severe fibrosis in rat lung. J Clin Invest 100(4): 768-776.
