Melanoma Stem Cell Sphere Formation Assay

Materials and Reagents

1. Cell culture flask, area 150 cm² (Corning, catalog number: 430823 )

2. 15 ml Falcon tube (Greiner Bio One International, catalog number: 188261 )

3. Micropipette P200 tips (Corning, catalog number: 4823 )

4. 24-wells plates flat bottom (Corning, Costar^®, catalog number: 3527 )

5. 70 μm cell strainer (Corning, Falcon^®, catalog number: 352350 )

6. 15 ml polystyrene serological pipets (Corning, Falcon^®, catalog number: 357551 )

7. Melanospheres are obtained as described by Perego et al., starting from cell suspension obtained from melanoma surgical specimens or from previously established melanoma cell lines after culturing in stem cell medium (SCM) (Perego et al., 2010)

8. RPMI

9. 10% FBS

10. Trypan blue solution, 0.4% (Sigma-Aldrich, catalog number: T8154 )

11. SCM (see Recipes)
1. DMEM:F-12, 1:1 mixture’ (Lonza, catalog number: BE12-719F )

2. Epidermal growth factor (EGF) (PeproTech, catalog number: AF-100-15 )

3. Basic fibroblast growth factor (bFGF) (PeproTech, catalog number: 100-18B )

4. D-glucose (Sigma-Aldrich, catalog number: G7021 )

5. Insulin (Sigma-Aldrich, catalog number: I6634 )

6. Putrescine dihydrochloride (Sigma-Aldrich, catalog number: P5780 )

7. Sodium selenite (Sigma-Aldrich, catalog number: S9133 )

8. Progesterone (Sigma-Aldrich, catalog number: P6149 )

9. Transferrin (Sigma-Aldrich, catalog number: T8158 )

10. Sodium bicarbonate (NaHCO₃) (Sigma-Aldrich, catalog number: S8761 )

11. 1x phosphate buffered saline (PBS) (Lonza, catalog number: 17-516 )

12. Bovine serum albumin (BSA) (Sigma-Aldrich, catalog number: A1933 )

13. HEPES buffer (Lonza, catalog number: BE17-737 )

14. L-glutamine (Lonza, catalog number: BE17-605E )

15. Penicillin-streptomycin (Lonza, catalog number: 17-602E )


Equipment

1. Automatic pipettor (PBI, catalog number: 857075 )

2. Tissue culture incubator with CO₂ input (Thermo Fisher Scientific, Thermo Scientific^TM, model: Forma^TM Series II 3110 )

3. Centrifuge (Eppendorf, catalog number: 5810 )

4. Hemocytometer (Marienfeld-Superior, Bürker, catalog number: 0640211 )

5. Optical microscope (Carl Zeiss, model: Axiovert 25 )


Procedure

Notes:

1. Work in tissue culture hood with sterile tools and equipment.

2. This procedure was optimized for melanoma cells. The general principle could be applied to cancer stem cells for other tissues, with optimization.


1. Prepare stem cell medium (SCM) and store it at 4 °C in the dark. SCM should be used within 3-4 weeks from preparation. It is also possible to prepare a concentrated solution (10x) with all the supplements (DMEM:F-12, 1:1 mixture supplemented with components listed above in the Materials and Reagents section from 6b to 6o). The concentrated medium can be stored at 20 °C up to 3 months. Growth factors (b-FGF and EGF) have to be added fresh directly to the medium.
   Note: If you are planning to set up a sphere formation assay (SFA) with cells not cultured as melanospheres (adherent melanoma cells are grown in RPMI + 10% FBS, fresh melanoma tissue suspension is obtained from the processing of melanoma post-surgery specimens), start from step 10 of this procedure. In case of cells cultured with serum, be sure all the serum is removed (wash your cells extensively) before plating in SCM.

2. Collect melanospheres from the culture flask in a 15 ml Falcon tube.

3. Centrifuge for 10 min at 30 x g at room temperature (RT).

4. Discard the supernatant.

5. Dissociate the pellet by pipetting up and down using a micropipette P200 tips for about 80-100 times in 100-200 μl of SCM.
   Note: To dissociate the pellet, place the tip at the bottom of the tubes and pipette up and down fast enough to suspend the pellet and the cells without making bubble (too gentle pipetting will result in not complete sphere dissociation). In our hands, mechanical dissociation was the best method in terms of cell viability and results reproducibility to obtain single cell suspension.

6. Suspend the dissociated melanospheres in 2 ml SCM.

7. Centrifuge for 10 min at 150 x g at room temperature (RT) and discard the supernatant.

8. Dissociate the pellet by pipetting up and down using a micropipette P200 tips for about 80-100 times.

9. Suspend the dissociated melanospheres in SCM and count.
   Note: Make sure to obtain a single cell suspension. If clusters are still present, repeat steps 6-9. Eventually the cell suspension could be further filtered through a 70 μm cell strainer.

10. Take the required number of live cells (determined after counting with a hemocytometer in presence of trypan blue solution 0.4% to exclude dead cells) and adjust to a final concentration of 100 cells/100 µl in SCM.

11. Pipette 400 µl/well of SCM in each 24-well plate for a total of 6 wells for each cell line or treatment.
    Note: In our hands, SFA was largely used to test cytokines and chemokines effect on melanoma stem cells self-renewal (Tuccitto et al., 2016). We think that melanoma SFA could be optimized also to test the effects of drugs (targeting stem cells markers or active signaling pathways) or growth factors on melanoma stem cell self-renewal and or viability.

12. Seed 100 µl of the cells in SCM (100 cells/well) for each well, prepare at least 4-6 replicates for each condition. The seeded cells should appear as singlets (see Figure 1A).


    Figure 1. Melanoma sphere formation. A. Single cell melanospheres plated in SCM; B. Doublets appearing when cells start dividing; C. Triplets formed during cell proliferation; D. Fully formed melanospheres. Total magnification 200x (A-D), scale bar = 20 µm.


13. Place the plate in an incubator set at 37 °C with 5% CO₂.

14. 24-72 h after seeding, the cells doublets and triplets will appear in wells and could be counted under an optical microscope (see Figures 1B and 1C).
    Note: If the media turns yellow, add fresh media to the well without dissociating or touching the ongoing forming spheres.

15. Melanospheres will be completely formed in each well 5-8 days after seeding and can be counted again under an optical microscope with 10x objective (total magnification 100x) analyzing the entire well. If spheres are bigger enough to be clearly distinguished from monolayer aggregates and single cells, also lower magnification should be used (20-50x total magnification). For better results, count melanospheres when they are clearly visible and do not let them over-proliferate. If this happen, melanospheres could attach to the plate and reliable counting will be difficult.
    Note: When melanospheres are formed (see Figure 1D) it is difficult to distinguish the exact number of cells due to their compact 3D structure. Occasionally, some monolayer aggregates of about 10-30 cells could be observed, but those aggregates shouldn’t be accounted as melanospheres (Figure 2). Generally, spheres could be counted around day 5 up to day 10 from SFA seeding, optimal counting time should be determined for each cell line or sample and then maintained constant across different experiments. To simplify the count of the spheres it could be useful drawing some line with a marker to subdivide the well into quarters.


    Figure 2. Non-melanosphere clusters. Example of non-spherical cluster that could be found in SFA. Those clusters could not be counted as spheres. Total magnification 200x, scale bar = 20 µm.


Data analysis

Sphere efficiency can be reported as percentage (%) of spheres formed dividing by the original number of cells seeded or number of spheres counted considering the total number of single cells seeded. We usually presented the results as mean ± SD (or SEM) of biological replicates. Each cell line was tested multiple times to be sure that the sphere forming efficiency was maintained after extensive cell culture.

Notes

1. Self-renewal efficiency it is cell-type or cell-line dependent, depending on the melanospheres origin. In our hands, melanospheres showed between 30% and 15% of sphere forming efficiency (Perego et al., 2010; Tuccitto et al., 2016).

2. Self-renewal efficiency is generally higher for cells maintained in culture as melanospheres than for cells previously cultured in regular melanoma culture medium with serum (adherent melanoma cultures). Melanospheres cultures are already enriched in CSC compared to adherent culture, so SFA from adherent cell lines would result in lower sphere forming efficiency, in general.


Recipes

1. Stem cell medium (SCM) (500 ml)
   DMEM:F-12 1:1 mixture
   10 ng/ml EGF
   5 ng/ml bFGF
   600 µg/ml D-glucose
   5 µg/ml insulin
   1 µg/ml putrescine dihydrochloride
   0.01 µg/ml sodium selenite
   0.01 µg/ml progesterone
   20 µg/ml transferrin
   0.11 µg/ml NaHCO₃
   4 mg/ml BSA
   119.2 µg/ml HEPES buffer
   292 µg/ml L-glutamine
   200 UI/ml penicillin-streptomycin
   Notes:
1. 10x BSA solution in 1x PBS can be stored at -20 °C.

2. If stock solution are made, make sure to respect the final volume of 500 ml, otherwise some components will be diluted and the media should not work.

Acknowledgments

This protocol was used in Perego et al., 2010 and Tuccitto et al., 2016. These works were supported by the Associazione Italiana Ricerca sul Cancro (CC IG-10615).
