Purification of FLAG-tagged Secreted Proteins from Mammalian Cells

Materials and Reagents

1. Pipette tips (VWR)

2. 12-well plate (Corning, Falcon^®, catalog number: 353043 )

3. 100 mm tissue culture dishes (Corning, Falcon^®, catalog number: 353803 )

4. Amicon Ultra 15 filtration units 3K (EMD Millipore, catalog number: UFC900308 )

5. 1.5 ml tubes (VWR, catalog number: 89000-028 )

6. 50 ml Falcon tubes (Corning, Falcon^®, catalog number: 352070 )

7. 1 ml syringes (Terumo Medical, catalog number: SS-01T )

8. 30 G needles (BD, catalog number: 305128 )

9. Flp-In T-rex 293 cell line (Thermo Fisher Scientific, Invitrogen^TM, catalog number: R78007 ) (Optional)

10. pcDNA5 FRT TO (Thermo Fisher Scientific, Invitrogen^TM, catalog number: V652020 ) (Optional)

11. Hygromycin B (NACALAI TESQUE, catalog number: 07296-11 ) (Optional)

12. Blasticidin (Wako Pure Chemical Industries, catalog number: 029-18701 ) (Optional)

13. Doxycycline (Takara Bio, Clontech, catalog number: 631311 ) (Optional)

14. Dulbecco’s modified eagle’s medium (DMEM) (Sigma-Aldrich, catalog number: D6546 )

15. Fetal bovine serum (FBS) (Biosera, catalog number: FB-1345/500 )

16. Anti-Flag M2 agarose beads (Sigma-Aldrich, catalog number: A2220 )

17. Penicillin-streptomycin (Thermo Fisher Scientific, Gibco^TM, catalog number: 15070063 )

18. Potassium acetate (KAc) (Sigma-Aldrich, catalog number: 236497 )

19. HEPES (Sigma-Aldrich, catalog number: H3375 )

20. Magnesium chloride (MgCl₂) (Sigma-Aldrich, catalog number: M8266 )

21. 3xFlag peptide (Sigma-Aldrich, catalog number: F4799 )

22. Phosphate buffered saline (PBS)

23. Growth medium (see Recipes)

24. Wash buffer (see Recipes)

25. Elution buffer (see Recipes)


Equipment

1. Pipettes (e.g., Gilson)

2. 37 °C, 5% CO₂ incubator (e.g., Panasonic Biomedical, catalog number: MCO-170AICUV-PE )

3. Tube rotator located in cold room (e.g., Fisher Scientific, catalog number: 88-861-049 )

4. Centrifuge (e.g., Eppendorf, model: 5804 )

5. Cell culture microscope (e.g., Carl Zeiss, Vienna, Austria)


Procedure

1. Generation of stable cell lines using the Flp-In T-rex 293 cell line (Figure 1)
   Note: The Flp-In T-rex 293 cell line is suitable for inducible, stable, and homogenous high expression of your 3xFLAG-tagged protein of interest. Transiently transfected cell line can be used as long as the transfection efficiency (determined by immunofluorescence) is more than 50%.


   Figure 1. Diagram of how to prepare stable Flp-in T-rex 293 cell lines. Transfect Flp-in T-rex 293 cells with plasmids (pcDNA5 FRT TO with gene of interest and pOG44 that contains a gene for flippase). The following day, the cells are cultured with hygromycin B to select cells that have incorporated the gene of interest at FRT site of genomic region. The polyclonal stable cell lines are homogeneous expression.


   1. Seed 1 x 10⁵ Flp-In T-rex 293 cells in each well of a 12-well plate.

   2. Incubate overnight when cells have reached approximately 50% of confluency, and transfect Flp-In T-rex 293 cells with pcDNA5 FRT TO containing your FLAG-tagged gene of interest and pOG44 plasmids.

   3. After 4-5 days of transfection, treat cells with 100 μg/ml hygromycin B and 15 μg/ml blasticidin for approximately 2 weeks.


2. Purification of FLAG-tagged protein
   1. Grow five 100 mm dishes of Flp-In T-rex 293 cells expressing the 3xFLAG-tagged protein in growth medium (see Recipes) supplemented with 10 μg/ml doxycycline for 1 day until cells are approximately 80% confluent.

   2. Change cell culture media to 10 ml DMEM containing 5% FBS with 10 μg/ml doxycycline and culture for 2 days.
      Note: 10% FBS medium may clog an Amicon centrifuge filter during the concentration step.

   3. Harvest the cell culture media (conditioned media) from all five 100 mm dishes of step B2 into a 50 ml Falcon tube.

   4. Centrifuge the conditioned media at 2,000 x g for 5 min at 4 °C.

   5. Transfer the supernatant into an Amicon centrifuge filter unit. Spin at 4,000 x g for 30-40 min.

   6. Repeat step B5 until the retention volume is less than 2 ml.

   7. Transfer the concentrated conditioned media into two 1.5 ml tubes (1 ml per tube).

   8. Add 100 μl pre-washed 50% FLAG M2 beads slurry to each tube.

   9. Incubate the beads at least 2 h while rotating at 4 °C.

   10. Wash the beads with 0.5 ml cold wash buffer (see Recipes) 4 times by spinning at 100 x g for 1 min. After the last wash, remove as much buffer as possible with minimal disruption of the beads using syringe needles.

   11. Incubate the beads with 0.2 ml elution buffer (see Recipes) for 1 h at room temperature and collect the purified FLAG-tagged protein after centrifugation.


Recipes

1. Growth medium (560.5 ml)
   500 ml DMEM
   55 ml 10% FBS
   5.5 ml 1% penicillin-streptomycin

2. Wash buffer (50 ml)
   5.5 ml 1 M KAc (110 mM)
   1 ml 1 M HEPES (pH 7.4) (20 mM)
   100 μl 1 M MgCl₂ (2 mM)
   Make up to 50 ml with Millipore water

3. Elution buffer (210 μl)
   10 μl 5 mg/ml 3xFlag peptide (0.25 mg/ml)
   200 μl 1x PBS


Acknowledgments

This protocol was adapted from Chen et al. (2017). This work was supported by JSPS KAKENHI (Young Scientists A) Grant Number 16H06167, MEXT KAKENHI (Scientific Research on Innovative Areas) Grant Number 16H01194 (to E. I.); a European Molecular Biology Organization Fellowship (to C.C.); the Medical Research Council, UK; and the European Research Council (Advanced Grant 269058) grant to M.d.B.

References

1. Chen, C., Itakura, E., Nelson, G. M., Sheng, M., Laurent, P., Fenk, L. A., Butcher, R. A., Hegde, R. S. and de Bono, M. (2017). IL-17 is a neuromodulator of Caenorhabditis elegans sensory responses. Nature 542(7639): 43-48.
